Device Type |
Wireless router - 4-port switch (integrated) |
Enclosure Type |
Desktop |
Data Link Protocol |
Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Capacity |
Virtual interfaces (VLANs) : 5 ¦ IPSec VPN tunnels : 5 |
Network / Transport Protocol |
TCP/IP, UDP/IP, L2TP, ICMP/IP, PPPoE |
Routing Protocol |
RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3, GRE |
Remote Management Protocol |
SNMP 1, SNMP 2, HTTP, HTTPS, TFTP |
VoIP Functionality |
VoIP phone adapter |
VoIP Protocols |
SIP v2 |
Telephony Interfaces |
2 phone (FXS), 1 line (FXO) |
Features |
Auto-sensing per device, NAT support, ARP support, VLAN support, reverse NAT support, auto-uplink (auto MDI/MDI-X), Syslog support, traffic shaping, Stateful Packet Inspection (SPI), DoS attack prevention, dynamic DNS server, DiffServ support, MAC address filtering, VPN passthrough, SNTP support, Low-latency queuing (LLQ), Weighted Fair Queuing (WFQ), IPSec Virtual Private Network (VPN), Wi-Fi Multimedia (WMM) support, event log, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), Wi-Fi Protected Setup (WPS), DHCP server, DNS proxy, port forwarding |
Compliant Standards |
IEEE 802.3u, IEEE 802.1Q, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n |
Power |
AC 120/230 V |
