Description
|
Specification
|
|
Dual WAN
|
• Dual Gigabit Ethernet Ports
• Failover
• Load balancing
|
|
Standards
|
• 802.3, 802.3u
• IPv4 (RFC 791)
• IPv6 (RFC 2460)
|
|
WAN Connectivity
|
• Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent
• Static IP
• Point-to-Point Protocol over Ethernet (PPPoE)
• Point-to-Point Tunneling Protocol (PPTP)
• Transparent bridge
• DNS relay, Dynamic DNS (DynDNS.org, 3322.org), DNS local database
• IPv6
|
|
Routing protocols
|
• Routing Information Protocol (RIP) v1 and v2, and RIP for IPv6 (RIPng)
• Inter-VLAN routing
• Static routing
• VLANs supported: 7
|
|
Network Address Translation (NAT)
|
• Port Address Translation (PAT)
• One-to-one NAT
• NAT traversal
|
|
Protocol binding
|
Protocols can be bound to a specific WAN port for load-balancing purposes
|
|
Network edge (DMZ)
|
• DMZ port
• DMZ host
|
|
Dual USB 2.0 ports
|
Storage and 3G/4G modem support
|
|
Security
|
|
Firewall
|
• SPI firewall
• Denial-of-service (DoS) prevention: ping of death, SYN flood, IP spoofing, WinNuke
|
|
Access rules
|
• Schedule-based access rules
• Up to 50 entries
|
|
Port forwarding
|
Up to 30 entries
|
|
Port triggering
|
Up to 30 entries
|
|
Blocking
|
Java, cookies, ActiveX, HTTP proxy
|
|
Content filtering
|
Static URL blocking or keyword blocking
|
|
Secure management
|
• HTTPS web access to device manager
• Username/password complexity enforcement
|
|
VLAN
|
802.1Q VLAN
7 VLANs supported
|
|
VPN
|
|
IP Security (IPsec)
|
• 25 IPsec site-to-site tunnels for branch office connectivity
• 25 IPsec VPN tunnels via Cisco VPN client and third-party clients such as "The GreenBow" for remote-access VPN connectivity
|
|
SSL VPN
|
10 SSL VPN tunnels for remote client access
|
|
PPTP
|
10 PPTP tunnels for remote access
|
|
Encryption
|
• Data Encryption Standard (DES)
• Triple Data Encryption Standard (3DES)
• Advanced Encryption Standard (AES) encryption: AES-128, AES-192, AES-256
|
|
Authentication
|
MD5/SHA1
|
|
IPsec NAT traversal
|
Supported for gateway-to-gateway and client-to-gateway tunnels
|
|
VPN pass-through
|
PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec
|
|
Advanced VPN
|
• Dead peer detection (DPD)
• Split DNS
• VPN backup
• Internet Key Exchange (IKE) with certificate
|
|
Quality of Service (QoS)
|
|
Service-based QoS
|
Rate control or priority
|
|
Rate control
|
Upstream/downstream bandwidth per service
|
|
Prioritization types
|
Application-based priority on WAN port
|
|
Priority
|
Services mapped to one of two priority levels
|
|
Performance
|
|
NAT throughput
|
900 Mbps
|
|
