Specifications
|
|
Dual WAN
|
Configurable for Smartlink backup or load balancing
|
|
Standards
|
• 802.3, 802.3u • IPv4 (RFC 791) • Routing Information Protocol (RIP) v1 (RFC 1058) and v2 (RFC 1723) |
|
Network protocols
|
• Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent • Static IP • Point-to-Point Protocol over Ethernet (PPPoE) • Point-to-Point Tunneling Protocol (PPTP) • Transparent bridge • DNS relay, Dynamic DNS (DynDNS, 3322) |
|
Routing protocols
|
• Static • RIP v1 and v2 |
|
Network Address Translation (NAT)
|
• Port Address Translation (PAT) • Network Address Port Translation (NAPT), NAT traversal, one-to-one NAT |
|
Protocol binding
|
Protocols can be bound to a specific WAN port for load balancing
|
|
Network edge (DMZ)
|
DMZ port, DMZ host
|
|
Security
|
|
Firewall
|
SPI, denial of service (DoS), ping of death, SYN flood, land attack, IP spoofing, email alert for hacker attack
|
|
Access rules
|
Up to 50 entries
|
|
Port forwarding
|
Up to 30 entries
|
|
Port triggering
|
Up to 30 entries
|
|
Blocking
|
Java, cookies, ActiveX, HTTP proxy
|
|
Content filtering
|
Static URL blocking or keyword blocking
|
|
Web filtering
|
Optional Cisco ProtectLink Web cloud-based security service
|
|
Secure management
|
HTTPS, username/password, password complexity
|
|
VPN
|
|
IPsec
|
100 IPsec site-to-site tunnels for branch office connectivity
|
|
QuickVPN
|
50 QuickVPN tunnels for remote client access
|
|
PPTP
|
5 PPTP tunnels for remote access
|
|
Encryption
|
Data Encryption Standard (DES), Triple Data Encryption Standard (3DES), and Advanced Encryption Standard (AES) encryption AES-128, AES-192, AES-256
|
|
Authentication
|
MD5/SHA1 authentication
|
|
IPsec NAT traversal
|
Supported for gateway-to-gateway and client-to-gateway tunnels
|
|
VPN pass-through
|
PPTP, L2TP, IPsec
|
|
Advanced VPN
|
Dead peer detection (DPD), IKE, split DNS, VPN backup
|
|
Quality of Service (QoS)
|
|
Prioritization types
|
Application-based priority on WAN port
|
|
Service-based QoS
|
Supports rate control or priority
|
|
Rate control
|
Upstream/downstream bandwidth can be configured per service
|
|
Priority
|
Each service can be mapped to one of 3 priority levels
|
|
Performance
|
|
NAT throughput
|
200 Mbps
|
|
IPsec VPN throughput
|
97 Mbps
|
|
Configuration
|
|
Web user interface
|
Simple browser-based device manager (HTTP/HTTPS)
|
|
Management
|
|
Management protocols
|
Web browser, Simple Network Management Protocol (SNMP) v1 and v2c, Bonjour
|
|
Event logging
|
Syslog, email alerts, VPN tunnel status monitor
|
|
Upgradability
|
Firmware upgradable through web browser, imported/exported configuration file
|
